OTC12


Del Medical OTC12


A sturdy and reliable overhead tube support that allows the most flexible configuration choices in radiographic systems. Combine with a table and wall bucky for an imaging system capable of all general purpose radiographic procedures.






Del Medical OTC12


A Del Medical OTC12 Overhead Tube Crane System offers the utmost in technologist efficiency and patient comfort. Start with the exceptionally easy to position, simple to use, ceiling mounted tube support that is available in both manual and automatic cassette size-sensing models allowing for the most flexible configuration choices available. The OTC12 can be configured with 300,000, 400,000 or 600,000 HU x-ray tubes and either manual or automatic collimators.


Benefits

Key benefits of the Del Medical OTC12D include:
  • Touch screen display for SID and angulation
  • Telescoping arm allows for small focus-to-ceiling distance
  • Ergonomic design with easy movements for fast, accurate positioning
  • Electromagnetic brake for telescopic lift and transverse track
  • Integrated lock function
  • Available with manual or automatic collimator with vertical tracking capability



Specifications

Tube Crane

Vertical telescope travel range: 70.8" (1800mm) with minimum 32.7" (830mm) focal spot floor distance with a 9' ceiling height
Longitudinal travel range: Standard 14' rail included, 136.2" min. (3460mm) With optional rail extensions: 219.9" max (5585mm)
Transverse travel range: STD 10' Bridge with 9.8' (3m) transverse carriage: 86.6" min. (2200mm) With 13' bridge & 13.1' (4m) transverse carriage: 139.7" max.(3550mm)
Longitudinal detent positions: Configurable during installation
Tube rotation range: Horizontal axis, -120°, +120°
Detent positions at -90°, 0°, +90°
Tube rotation range: Vertical axis, -182°, +154°
Detent positions at -180°, -90°, 0°, +90°
Weight: Approximately 831 lbs. (377 kg) with tube & collimator
Power Requirements: 110/240 Vac. 50/60 Hz, 700 VA
